User’s Manual of GS-4210 Series
The Remote Syslog screens in Figure 4-2-16 & Figure 4-2-17 appear.
Figure 4-2-16 Remote Log Target Page Screenshot
The page includes the following fields:
Object Description
 Server Address
Provide the remote syslog IP address of this switch.
 Server Port
Provide the port number of remote syslog server.
Default Port no.: 514
 Severity
The severity of the local log entry. The following severity types are supported:
 emerg: Emergency level of the system unstable for local log.
 alert: Alert level of the immediate action needed for local log.
 crit: Critical level of the critical conditions for local log.
 error: Error level of the error conditions for local log.
 warning: Warning level of the warning conditions for local log.
 notice: Notice level of the normal but significant conditions for local log.
 info: Informational level of the informational messages for local log.
 debug: Debug level of the debugging messages for local log.
 Facility
Local0~7: local user 0~7
Buttons
: Click to apply changes.
Figure 4-2-17 Remote Log Setting Status Page Screenshot
The page includes the following fields:
Object Description
 Status
Display the current remote syslog state
68

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
