User’s Manual of IGS-4215-16T2S
4.13.10.7 ACL Binding
This page allows you to bind the Policy content to the appropriate ACLs. The ACL Policy screens in Figure 4-13-78 and Figure
4-13-79 appear.
Figure 4-13-78: ACL Binding Page Screenshot
The page includes the following fields:
Object Description
• Binding Port
Select port from this drop-down list.
• ACL Select
Select ACL list for this drop down list.
Buttons
: Click to apply changes.
Figure 4-13-79: ACL Binding Table Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• MAC ACL
Displays the current MAC ACL.
• IPv4 ACL
Displays the current IPv4 ACL.
• IPv6 ACL
Displays the current IPv6 ACL.
• Modify
Click to edit ACL binding table parameter.
Click to delete ACL binding entry.
