User’s Manual of IGS-4215-16T2S
322
Buttons
: Click to add ACE list
Figure 4-13-77: IPv6-based ACE Table Page Screenshot
The page includes the following fields:
Object Description
• ACL Name
Displays the current ACL name.
• Sequence
Displays the current sequence.
• Action
Displays the current action.
• Protocol
Displays the current protocol.
• Source IP Address
Displays the current source IP address.
• Source IP Address
Wildcard Mask
Displays the current source IP address wildcard mask.
• Destination IP Address
Displays the current destination IP address.
• Destination IP Address
Wildcard Mask
Displays the current destination IP address wildcard mask.
• Source Port Range
Displays the current source port range.
• Destination Port
Range
Displays the current destination port range.
• Flag Set
Displays the current flag set.
• DSCP
Displays the current DSCP.
• IP Precedence
Displays the current IP precedence.
• ICMP Type
Displays the current ICMP Type.
• ICMP Code
Displays the current ICMP code.
• Modify
Click to edit IPv6-based ACL parameter.
Click to delete IPv6-based ACL entry.
