2. File holder If you are using a hand file with the apex locator,
insert the file holder's grey male plug into the grey
female connector on the probe cord.
If you are using the Morita TORX micromotor and
the CA-10RC-ENDO 10:1 handpiece with the apex
locator, do not use the file holder. Leave the grey
female connector on the probe cord hanging.
3. Contrary electrode Insert the contrary electrode into the white female
connector on the probe cord.
NOTE
Always grip the connector to connect/disconnect the probe cord. Never pull
or yank on the cord itself.
Before treating a patient:
• Make sure that the probe cord is securely plugged into the jack on the
back of the instrument console.
Planmeca Compact i dental unit with hanging-tube instruments
22 Operating instruments
122 Planmeca Compact i3 User's manual
