9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
1.17
STEERING / SUSPENSION
GENERAL SPORT/
GENERAL PREMIUM
GENERAL DELUXE GENERAL XP
Steering Wheel Free-Play 0.8-1.0 in (20-25 mm)
Toe Out
0-1/8 in (0-3.175 mm)
Front Suspension
Independent Dual A-Arm
ZF Sachs Twin Tube
Independent Dual A-Arm
FOX™ Podium QS3
Independent Dual A-Arm
Walker Evans Velocity
Front Travel
12.25 in (31 cm) 14 in (35.5 cm)
Rear Suspension
Independent Dual A-Arm
ZF Sachs Twin Tube
Independent Dual A-Arm
FOX™ Podium QS3
Independent Dual A-Arm
Walker Evans Velocity
Rear Travel
13.2 in (33.5 cm) 14 in (35.5 cm)
Spring Adjustment Threaded Spanner Wrench Threaded Spanner Wrench Threaded Spanner Wrench
WHEELS / BRAKES
GENERAL SPORT
GENERAL PREMIUM /
GENERAL DELUXE
GENERAL XP
Front Wheel / Size
Stamped Steel / 12 x 6
Cast Aluminum / 14 x 6 Cast Aluminum / 15 x 7
Rear Wheel / Size
Stamped Steel / 12 x 8
Cast Aluminum / 14 x 8 Cast Aluminum / 15 x 7
Front Tire Size / Model 27 x 9-12 / Clincher 27 x 9-14 / Maxxis Coronado 30 x 10-15 / Crawler XG
Rear Tire Size / Model 27 x 11-12 / Clincher 27 x 11-14 / Maxxis Coronado 30 x 10-15 / Crawler XG
Tire Air Pressure
Front: 10 psi (69 kPa)
Rear: 18 psi (124 kPa)
Front: 12 psi (87 kPa)
Rear: 14 psi (96 kPa)
Front: 10 psi (69 kPa)
Rear: 14 psi (96 kPa)
Brake System
Front & Rear
Foot Actuated 4 Wheel Hydraulic
Dual Bore Caliper
Foot Actuated 4 Wheel
Hydraulic
Front: Dual Bore Caliper &
Rear: Single Bore Caliper
Brake Fluid DOT 4
STANDARD 2 SEAT MODELS
CLUTCHES
ALTITUDE SHIFT WEIGHT DRIVE SPRING DRIVEN SPRING
0-1800 Meters
(0-6000 Feet)
35-67
(1323686)
58-135
(7044263)
7044505
1800-3700 Meters
(6000-12000 Feet)
35-61
(1323687)
58-135
(7044263)
7044505
XP MODELS
CLUTCHES
ALTITUDE SHIFT WEIGHT DRIVE SPRING DRIVEN SPRING
0-1800 Meters
(0-6000 Feet)
35-76
(1327101)
58-135
(7044263)
7044506
1800-3700 Meters
(6000-12000 Feet)
35-67
(1323686)
58-135
(7044263)
7044506
