11.76
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
FRONT FENDER FLAIR INSTALLATION
1. Install the fastener holding the front fender flair to the
front fender. Torque the fastener to specification.
TORQUE
Front Fender Flair Fastener:
3.5 lb-ft (4.7 Nm)
2. Install the hood onto the vehicle. Refer to “Hood
Installation” page 11.76 procedure.
HOOD INSTALLATION
1. Install the hood on the vehicle and align the latches.
2. Rotate the latches 90° to secure the hood.
SEAT INSTALLATION
1. To install the seats, install the front tabs of the seat
base assembly into the mounting bracket.
2. Press down on the back of the seat to latch the seat
onto the frame. Lift up on the seat to ensure it is fully
installed.
BODY / FRAME
