REAR FENDER FLAIR INSTALLATION
1. Install the fasteners holding the rear fender flair to the
rear fender.
2. Close the cargo box and secure in position.
LOWER CENTER FENDER INSTALLATION
1. Install the center lower fender tabs into of the rocker
panel. Install the fasteners holding the center lower
fender to the vehicle. Torque fasteners to
specification.
TORQUE
Center Lower Fender Fasteners:
3.5 lb-ft (4.7 Nm)
UPPER CENTER FENDER INSTALLATION
1. Install the fasteners holding the center upper fender
to the vehicle.
FRONT FENDER INSTALLATION
1. Install the fasteners holding the front fender to the
vehicle. Torque the fasteners to specification.
TORQUE
Front Fender Fasteners:
3.5 lb-ft (4.7 Nm)
