9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
9.81
SHOCK SPECIFICATIONS - GENERAL XP 4
NOTE
All Walker Evans valve code measurements are in inches.
Valve shim stacks listed as they would appear on the shaft when shock rod is locked in a table vise (eyelet down,
threaded end up).
SHOCKS
Shocks
LH Front - 7045311
RH Front - 7045312
Rear - 7045323
Model
Walker Evans 2.0 Velocity Walker Evans 2.5 Velocity
Extended Length
(inches)
24.866 25.051
Collapsed Length
(inches)
17.575 16.674
Stroke
(inches)
7.291 8.377
Shock Rod
(inches)
.625 0.750
IFP Depth
(inches)
2.875
Bottom of reservoir to bottom of
floating piston
3.75
Bottom of reservoir to bottom of
floating piston
Oil Volume Full Full
PSI 150 150
STEERING / SUSPENSION
