FRONT FENDER FLAIR INSTALLATION
1. Install the fastener holding the front fender flair to the
front fender. Torque the fastener to specification.
TORQUE
Front Fender Flair Fastener:
3.5 lb-ft (4.7 Nm)
2. Install the hood onto the vehicle. Refer to “Hood
Installation” page 11.76 procedure.
EXTERIOR BODY COMPONENT
INSTALLATION - GENERAL 4
HOOD LINER INSTALLATION
1. If removed, install fasteners holding the hood liner to
the vehicle.
2. Install the fasteners and clamps securing the pulse
bar mounting bracket, intake duct, and coolant surge.
Torque fasteners to specification.
TORQUE
Pulse Bar Fasteners:
3 lb-ft (4 Nm)
Intake Duct Hose Clamp:
3 lb-ft (4 Nm)
Coolant Surge Tank Fasteners:
2 lb-ft (2.7 Nm)
