13.48
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
4. Install the four speaker cover fasteners
q
. Torque
fasteners to specification.
TORQUE
Speaker Cover Fasteners:
7 in-lbs (.75 Nm)
SUBWOOFER SERVICE
REMOVAL
1. Remove hood.
2. If windshield is installed, then open or remove it as
required to gain access to upper dash.
3. Remove five push pin rivets
q
from front side of
panel, and two push pin rivets
w
from outboard ends
of panel. Retain rivets.
4. Slide panel upward and rearward, detaching eight
spring clips. Set dash aside.
FACTORY-INSTALLED OPTIONS
