TRANSMISSION VENT LINE
TRANSMISSION VENT LINE ROUTING
The transmission vent line runs up towards the passenger frame rail and through an open section of the frame to a
vent line termination fitting.
q
Hose Clamp
e
Vent Line Termination Fitting
w
Vent Line
