11.88
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
3. Remove the fasteners that hold the front RH and LH
ROPS to the vehicle frame and center ROPS.
4. Remove the fasteners that hold the rear RH and LH
ROPS to the center and rear ROPS.
5. Pull the cargo box handle and lift the cargo box out of
the way.
6. Remove the fasteners holding the seat belt shoulder
strap assemblies to the center and rear ROPS.
7. Remove the fasteners that hold the rear ROPS to the
vehicle frame.
8. Remove the fasteners that hold the center ROPS to
the vehicle frame.
ROPS INSTALLATION - GENERAL 4
NOTICE
Loosely install ROPS onto vehicle with all fasteners
before beginning to torque fasteners.
1. Loosely install the fasteners that hold the center
ROPS to the vehicle frame.
2. Pull the cargo box handle and lift the cargo box out of
the way.
3. Loosely install the fasteners that hold the rear ROPS
to the vehicle frame.
BODY / FRAME
