13.20
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
FRONT BUMPER INSTALLATION
1. Install the front bumper on the vehicle and align
mounting points. Install the front bumper lower
mounting fasteners and torque to specification.
TORQUE
Front Bumper Fasteners:
30 lb-ft (41 Nm)
2. Install the front bumper upper mounting fasteners and
torque to specification.
TORQUE
Front Bumper Fasteners:
30 lb-ft (41 Nm)
3. Install the upper mounting fastener end caps from the
front bumper.
4. Install the pin attaching the winch hook.
FACTORY-INSTALLED OPTIONS
