9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
12.5
SPECIAL TOOLS - ELECTRICAL
SYSTEM
TOOL DESCRIPTION
PART
NUMBER
Digital Wrench® Diagnostic Software
(Includes most recent version of
software w/serial number, standard
interface cable, USB-Serial Adaptor
cable and SmartLink Module Kit)
PU-47063-B
Digital Wrench® SmartLink Module
Kit
(PU-47470, PU-47469, PU-47468)
PU-47471
Digital Wrench®
PC Interface Cable
PU-47470
Digital Wrench®
Vehicle Interface Cable
PU-47469
Digital Wrench®
SmartLink Module
PU-47468
Digital Wrench®
Wireless Vehicle Link (WVL)
PU-51435
Fluke™ 77 Digital Multimeter
PV-43568
Static Timing Light Harness
2871745
Hall Effect Sensor Probe Harness 2460761
Battery Conductance Analyzer
(MDX-610P)
PU-50296
Connector Test Kit PV-43526
Timing Light
2870630
Relay Bypass
PU-49466
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com/
SERVICE SPECIFICATIONS -
ELECTRICAL SYSTEM
PART DESCRIPTION
SERVICE
SPECIFICATION
Stator Leg to Leg
Resistance
0.07 - 0.13 Ω
Stator Leg to Ground
Resistance
Open Line (OL / ∞)
Stator Leg Voltage (1300
RPM)
21 VAC ± 25%
Stator Leg Voltage (3000
RPM)
47 VAC ± 25%
Stator Leg Voltage (5000
RPM)
79 VAC ± 25%
Starter Solenoid Terminal
Resistance (77 °F)
0 - 0.5 Ω
CPS Resistance 1000 Ω ± 10%
ECT Resistance (77 °F /
25 °C)
29.9 kΩ ± 6%
ECT Resistance (248 °F /
120 °C)
1.22 kΩ ± 2%
AWD Hub Coil Resistance 24 Ω ± 5%
Current Draw - Key Off
(Max)
.01 DCA (10 mA)
CHASSIS / BODY ELECTRICAL
