9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
5.5
EVAP FUEL SYSTEM ASSEMBLY VIEW
q
Fuel Fill Neck and Fuel Cap
q
Carbon Canister Fasteners
72 in-lbs (8 Nm)
1(
Panduit Strap
w
Fuel Tank
s
Carbon Canister Bracket Mount
2)
Hinged Routing Clip
e
Fuel Pump Assembly
d
Carbon Canister
2!
Vent Line Termination Fitting
r
PFA Nut
70 lb-ft (95 Nm)
f
Carbon Canister to Canister Filter
Line
2@
Purge Valve Fasteners
72 in-lbs (8 Nm)
t
Routing Clip
g
Carbon Canister Filter 2#
Purge Valve Bracket
y
Fuel Feed Line
h
Carbon Canister Filter Mount 2$
Purge Valve
u
Vent Rollover Valve
j
Carbon Canister Filter Fastener
72 in-lbs (8 Nm)
2%
Purge Valve to Throttle Body Line
i
Hinged Routing Clip
k
Carbon Canister to Purge Valve
Line
2^
Panduit Strap
o
Fuel Vent Line
l
Carbon Canister Vent Line
FUEL SYSTEM
