13
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
13.13
SIDE MIRROR REMOVAL (INTL)
1. Remove the mirror from the mirror bracket and cover.
2. If mirror bracket removal is required, remove the
plastic push rivet and remove the mirror bracket
cover.
3. Remove the two ROPS fasteners securing the mirror
bracket and ROPS to the vehicle frame. Remove the
mirror bracket.
SIDE MIRROR INSTALLATION (INTL)
1. If removed, the mirror bracket and two ROPS
fasteners. Torque fasteners to specification.
TORQUE
Side ROPS Fasteners:
40 lb-ft (54 Nm)
2. Install the mirror bracket cover over the mirror bracket
and install plastic push rivet to secure the cover.
FACTORY-INSTALLED OPTIONS
