9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
FRAME COMPONENT INSTALLATION
ROPS REMOVAL
1. Remove the fasteners that hold the visor panel to the
front cross.
2. Remove the fasteners that hold the front cross to the
RH and LH ROPS.
3. Remove the fasteners that hold the RH and LH
ROPS to the vehicle frame and rear ROPS.
4. Pull the cargo box handle and lift the cargo box out of
the way.
5. Remove the fasteners that hold the rear ROPS to the
vehicle frame.
ROPS INSTALLATION
NOTICE
Loosely install ROPS onto vehicle with all fasteners
before beginning to torque fasteners.
1. Pull the cargo box handle and lift the cargo box out of
the way.
2. Loosely install the fasteners that hold the rear ROPS
to the vehicle frame.
3. Close the cargo box and secure in position.
BODY / FRAME
