CHASSIS HARNESS (INTL)
HARNESS COMPONENT LOCATIONS - INTL (NON-ABS)
FRONT VIEW
q
RH Headlight
f
Brake Fluid Level Switch
2%
Key Switch
w
RH Front Turn Signal
g
Pedal Position Sensor
2^
12V Receptacle HI (Dash)
e
Voltage Regulator AC Input
h
Brake Pedal Switch
2&
Hazard Switch
r
Voltage Regulator DC Out
j
Operator Alarm Signal
2*
12V Receptacle LO (Dash)
t
Winch Contactor
k
Operator Alarm B+
2(
Fog Light Switch
y
Fan
l
LED Light #1
3)
LED Light #5
u
Horn Ground
1(
Winch Switch
3!
Infotainment
i
Horn Enable
2)
AWD/2WD/TURF Switch
3@
LED Light #3
o
AWD Coil
2!
Turn/Light/Horn Switch
3#
Flasher Module
a
LH Headlight
2@
Speedometer
3$
Diagnostic
s
LH Front Turn Signal
2#
EPS Power
3%
Pulse Bar
d
Brake Pressure Switch
2$
EPS Signal
