9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
13.65
VEHICLE-TO-VEHICLE (V2V) ANTENNA
SERVICE (2-SEAT)
REMOVAL
1. Disconnect the V2V antenna connector from RIDE
COMMAND
®
harness .
2. Remove the edge clips securing the antenna harness
to the roof panel.
3. Remove roof bracket and V2V antenna by removing
two roof bracket fasteners.
4. To remove the V2V antenna from the antenna
bracket, open the clamshell cover. Loosen slotted nut
and carefully remove antenna by pulling upward and
routing antenna cable through holes in clamshell
cover and bracket. Remove the slotted nut, slotted
washer, and rubber washer from the cable.
q
V2V antenna
r
Rubber Washer
w
Antenna bracket
t
Slotted Washer
e
Clamshell Cover
y
Slotted Nut
5. If required, remove the fastener securing the antenna
bracket to the roof bracket.
FACTORY-INSTALLED OPTIONS
