9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
9.53
SHOCK SERVICE - GENERAL / GENERAL 4
SHOCK SPECIFICATIONS - GENERAL
NOTE
All FOX valve code measurements are in inches.
Valve shim stacks listed as they would appear on the shaft when shock rod is locked in a table vise (eyelet down,
threaded end up).
SHOCKS
Shocks
LH Front - 7044415
RH Front - 7044416
LH Rear - 7044417
RH Rear - 7044418
Model
Fox 2.0 Podium QS3 Fox 2.0 Podium QS3
Extended Length
(inches)
22.52 22.47
Collapsed Length
(inches)
15.80 14.95
Stroke
(inches)
6.72 7.52
Shock Rod
(inches)
0.621 0.621
IFP Depth
(inches)
3.00
Bottom of reservoir to bottom of
floating piston
3.20
Bottom of reservoir to bottom of
floating piston
Oil Volume Full Full
PSI 100 100
STEERING / SUSPENSION
