9.70
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
EYELET-MOUNTED REBOUND ADJUSTER
1. Install Dust Plug.
2. Apply Slick Honey® to rebound adjuster.
3. Insert spring.
4. Put the steel ball on the spring with a dab of shock oil.
5. Install rebound knob into eyelet, holding steel ball in
place with fingers. Ensure rebound knob threads into
eyelet correctly, and you can feel the detents click.
NOTICE
Adjust rebound knob to allow metering rod to obtain
maximum travel in eyelet.
6.
7. Install a NEW O-ring on needle and apply thin layer of
Slick Honey.
STEERING / SUSPENSION
