Polaris General 2020

10.24
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
BRAKE SYSTEM RETENTION
q
Master Cylinder
s
RH Front Scraper
w
Master Cylinder Shield
d
Routing Clip
e
Washer
f
Brake Line Retention Fastener
8 lb-ft (11 Nm)
r
Master Cylinder Fasteners
22 lb-ft (30 Nm)
g
Nut
t
Outer Brake Line Clip
h
Wire/Tube Clamp
y
LH Front Scraper
j
Rivet
u
Scraper Fasteners
7 lb-ft (9 Nm)
k
Rear Caliper Fasteners
46 lb-ft (62 Nm)
i
Front Caliper Fasteners
30 lb-ft (41 Nm)
l
Junction Block Fasteners
35 in-lbs (4 Nm)
o
Inner Brake Line Clip
1(
Routing Clip
a
Rivet
2)
Nut
BRAKE SYSTEM
