11
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
11.19
SEAT BELT MOUNTING
q
Seat Belt Asm.
u
Nut
w
Nut
i
T-Rail Bracket Mount Fasteners
3.5 ft-lbs (5 Nm)
e
Seat Belt / Buckle Fasteners
40 lb-ft (54 Nm)
o
T-Rail Bracket Mount
r
Seat Belt Buckle
a
LH T-Rail Bracket
t
Seat Belt Buckle
s
Nut
y
Seat Belt Adjuster Mount Fastener
3.5 ft-lbs (5 Nm)
d
RH T-Rail Bracket
BODY / FRAME
