Polaris General 2020

11
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
11.25
TAILGATE
q
Tailgate Panel Fasteners
22 in-lbs (2.5 Nm)
i
Trim Clip
w
Inner Tailgate Panel
o
Hitch Pin
e
Tailgate Cable
a
Tailgate Latch Spring
r
Tailgate Rod
s
Inner Tailgate Pivot Bracket Fasteners
22 in-lbs (2.5 Nm)
t
Outer Tailgate Panel
d
Tailgate Pivot Bracket
y
Tailgate Handle Latch
f
Outer Tailgate Pivot Bracket Fasteners
3 ft-bs (4 Nm)
u
Tailgate Trim Panel
BODY / FRAME
