11.84
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
19.Mark the nut with a paint pen.
20.Tighten the nut an additional 3–4 turns in relation to
the paint mark.
21.Tighten the door handle side M10 nut.
22.Push door latch into double lock position.
23.Open interior door handle slowly.
NOTICE
The interior door handle should be about 3/4 of the way
through its throw when it releases the latch. Adjust
cable if necessary.
REAR DOOR CABLE ADJUSTMENT
NOTICE
Only applicable to General 4 Models.
1. Remove seven door panel fasteners.
2. Locate door cable adjuster.
3. Loosen door cable adjuster.
4. Push door latch into double lock position.
BODY / FRAME
To Next Page
