4.18
9924707 - 2013–2014 RZR 800 Service Manual
© Copyright 2013 Polaris Sales Inc.
4. Using special tool (PA-48873), torque the (3) bolts
that retain the front portion of the mounting bracket to
the transmission.
Upper Transmission Bolt
Middle Transmission Bolt
Bottom Transmission Bolt
5. Remove the special tool and attach an extension to
the torque wrench. Torque the bottom bolt that
attaches the bracket to the rear gearcase through
the hole in the frame support.
Bottom Rear Gearcase Bolt
NOTE: Special Tool is not required for this
torque.
ELECTRONIC FUEL INJECTION
