Operating Specifications12.4
Envelope Dimensions and Weights
Max. Length: 330 mm / 13"
Max. Width: 254 mm / 10"
Flap max. Height: 76 mm / 3"
- Min.Thickness: 0.2 mm / 1/64"
- Max.Thickness (Auto Feeder): 12.7 mm / 1/2"
- Max.Thickness (Sealing ON): 9.52 mm / 3/8"
- Max.Thickness (Manual Feed): 10 mm / 25/64"
Stack of Envelopes
Auto Feeder: max 102 mm / 4" high
Min. Weight: 2.85 g / 0.1 oz
Max. Weight: 1.2 kg / 2 lb 10.3 oz.
Label dimensions (pre-cut and self-adhesive)
Max. width: 40 mm / 1 37/64"
Min. length: 150 mm / 5 29/32"
Labels must be longer to print slogans.
Label storage: recommended room temperature 25°C (77°F) and
relative humidity 50%.
243
| Page 243 | | Jan-13-2017 10:45 |
