134
minutes.
SD Residue Size: the remaining capacity of the SD card.
DL1_A: UP/DL1-B: DOWN: make the yellow select box up or down by press the button DL1 to
select the function you need.
PS3: press the button PS3 to back the previous setting menu.
HOME: at the update mode, by pressing the power button to confirm the setting/select.
USB MODEL: press power button selects the “USB MODEL” to make the SD card of RC8X
connect to the computer
Update the latest: update the latest firmware that saved in the SD card of RC8X
Upgrade the specified: update the specified firmware that saved in the SD card of RC8X
Power off: exit the update setting menu and the RC8X will turn off at the same time.
The setting steps as below:
1
keep the RC8X power off,
2
use a USB cable (type-c) connect the RC8X to the computer.
3
Push DT1 and DT2 TRIM buttons to the middle at the same time, and then long press the
power button to enter the data copy and upgrade mode. The following four options will appear

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
