20
ESP-LXIVM Series Controllers
Programming Checklist
When programming the ESP-LXIVM controller for the first time, it is
recommended that you complete the following steps in order.
Set Up Hardware
Install IVM 2-Wire interface module .............................page 109
Apply 2-Wire Device Labels............................................. page 17
Fill out Programming Guide ........................................... page 18
Clear program information ............................................. page 93
Select language ................................................................... page 19
Set the current date and time ........................................ page 23
Set up master valves (optional) ..................................... page 24
Set up weather sensors (optional) ................................ page 26
Set up stations ..................................................................... page 28
Set up flow sensors (optional) ........................................ page 31
2-Wire Mapping ................................................................... `
Set Up Programs
Select program .................................................................... page 41
Set watering start times ................................................... page 42
Select watering days *....................................................... page 42
Set station run time(s) ....................................................... page 43
* See Watering Cycles dial position for Odd, Odd31, Even and
Cyclical watering cycles.
Set Up Programs (Optional)
Set seasonal adjust ............................................................. page 68
Create a water window ..................................................... page 73
Set up a station delay ........................................................ page 36
Set up Simulstations .......................................................... page 36
Review Setup
Confirm program ................................................................ page 55
Test stations .......................................................................... page 49
Check 2-Wire setup ............................................................ page 24
Check installed modules .................................................. page 109
Optional Setup
Check weather sensor status ..........................................page 61
Schedule calendar days off ............................................. page 72
Create a MV manual water window ............................. page 99
Set Cycle+Soak™ ................................................................. page 33
Set flow units ........................................................................ page 89
Activate Flo-Manager® ...................................................... page 83
Activate FloWatch™ ............................................................ page 84
Set up High Flow and Low Flow actions .................... page 86
Set controller to AUTO ...................................................... page 21
