58
ESP-LXIVM Series Controllers

The Total Run Time screen appears and total Run Time is shown
for the currently selected program.

NOTE: If the desired program is not selected, press the Program
Select button to choose the desired program. See "Program
Select Button" on page 41 for more details.

Total Run Time
HH : MM
02 : 30
PGM 01
Done

NOTE: For stations set up for Cycle+Soak, the Cycle Time
(when irrigation is occurring) will be included in Program Run
Time calculations but Soak times will NOT be included. See
"Cycle+Soak™" on page 33 for more details.

Change the Program Select switch and repeat this process to
review and confirm Program Run Times for other programs as
desired.
Program Run Times
Review total Run Time for an individual program.
Turn the controller dial to Diagnostics

At the DIAGNOSTICS screen, press the Down Arrow key to select
Confirm Programming, then press Next.

At the CONFIRM PROGRAMS screen, press the Down Arrow key
to select Program Run Times, then press Next.

DIAGNOSTICS
Test All Stations
Next
Diagnostics
Confirm Programming

CONFIRM PROGRAMS
Program Summary
Next
Review Programs
Program Run Times
Station Run Times
Review Master Valves
