ESP-LXIVM Series Controllers
Basic Programming
Program Select Button
Begin programming by pressing the Program Select button.
• The LX-IVM has 10 independent Programs available and the LX-
IVM Pro has 40 independent Programs available.
Multiple programs allow you to set watering schedules to meet dif-
ferent requirements for plant materials, soils, slopes, and shady or
sunny areas. Programs can operate simultaneously with the only
limitation being the number of stations you program to run simul-
taneously.
Select Program

On the controller front panel, press the Program Select + Key to
begin programming.


At the PROGRAM SELECT screen, Press the Arrow keys to select a
Program.

PROGRAM SELECT
PGM 01
Done
PGM 02
PGM 03
PGM 04

NOTE: When programming the controller, any program-specifi c
information you enter, such as start times or watering days, will
aff ect only the selected program.
Back Button

During programming, press the Back button to go back to the
previous screen.

