ESP-LXIVM Series Controllers
Turn the dial to 2-Wire Settings
At the Advanced Station Settings screen, press the Down Arrow
key to select 2-Wire Mapping, then press Next.
At the 2-Wire Device Mapping screen, press the + and – keys to
set the desired hour (from 0 to 23), then press the Right Arrow
key.
Cycle & Soak
Inter-Station Delay
SimulStations
2-Wire Mapping
Station Sequencing
Advanced Station Settings
2-Wire Device Mapping
HH:MM
Start Device Mapping In
00 00:
Press the + and – keys to set the desired minute (from 1 to 59), then
press Next.
At the confirmation screen, press Start to begin Device Mapping.
NOTE: All irrigation is disrupted during the mapping process.
2-Wire Device Mapping
Start Device Mapping In
HH:MM
01
05:
and could take several
interrupt all irrigation
Device Mapping will
Attention
minutes
A confirmation screen shows the process is set to run.
Mapping
Mins.
In 1 Hrs and 5
Mapping will begin
