75
ESP-LXIVM Series Controllers
Set Flow Rates
The LX-IVM controller lets you set the flow rates you expect or to
automatically Learn Flow rates based on real usage.
If you do not have flow sensing hardware installed you may be able
to estimate flow rates based on the irrigation hardware installed on
a particular station or FloZone and manually enter this rate.
FloZone flow rates are either:
Automatically set to the highest station flow rate assigned to the
FloZone, or
Manually adjusted by the user.
Learn Flow Automatically
NOTE: To ensure accurate recording of flow rates, do not create
any manually-generated flow such as flow created with manu-
ally operated quick coupling valves, while a Learn Flow is taking
place.
All Stations
NOTE: Ensure you have Run Times set up for all stations included
in a Learn Flow exercise prior to setting up a Learn Flow.
Turn the controller dial to Flow Sensor

At the FLOW SENSOR screen, with Set Flow Rates selected, press
Next.

At the Set Flow Rates screen, with Learn Flow selected, press Next.
FLOW SENSOR
Next
Current Flow Reading
Set Flow Units
Set FloWatch
Set FloManager
Set Flow Rates
Set Flow Rates
Next
View Flow Rates
Clear Flow Rates
Set FloZone Rates
Set Station Rates
Learn Flow
