Remote control commands
R&S
®
NRPxxS(N)
110User Manual 1177.5079.02 ─ 15
All R&S NRPxxS(N) power sensors allow compensating for the influence of any 2-port
device between the signal source and the power sensor input. As a result, the firmware
can calculate the power that the signal source actually delivers. Examples of such 2-
port devices include attenuators, matching pads, minimum-loss pads and waveguide
adapters. One precondition for such compensation is that you provide a complete set
of S-parameter data for the 2-port device in the frequency range required by the appli-
cation.
Configuring the S-parameter correction
[SENSe<Sensor>:]CORRection:SPDevice:LIST?.............................................................. 110
[SENSe<Sensor>:]CORRection:SPDevice:SELect.............................................................110
[SENSe<Sensor>:]CORRection:SPDevice:STATe..............................................................110
[SENSe<Sensor>:]CORRection:SPDevice:LIST?
Queries the list of the S-parameter data sets that have been downloaded to the power
sensor. The result of the query indicates the consecutive number and mnemonic of
each data set.
Usage:
Query only
[SENSe<Sensor>:]CORRection:SPDevice:SELect <num>
Selects a downloaded data set for S-parameter correction.
See also Chapter 9.8.4.3, "S-parameter correction", on page 109.
Parameters:
<num> Range: 1 to 1999
*RST: 1; can differ if a calibration set defines another
value.
[SENSe<Sensor>:]CORRection:SPDevice:STATe <state>
Enables or disables the S-parameter correction. If activated, uses the S-parameter
data set selected by [SENSe<Sensor>:]CORRection:SPDevice:SELect.
See also Chapter 9.8.4.3, "S-parameter correction", on page 109.
Parameters:
<state> *RST: OFF; can differ if a calibration set defines another
value.
Example:
CORR:SPD:SEL 1
Selects an S-parameter correction data set.
CORR:SPD:STAT ON
Enables the S-parameter correction.
Configuring basic measurement parameters
