Power Points
Defines the number of points for the power sweeps at each point on the frequency grid
defined using Start Frequency/Stop Frequency.
Remote command:
[SENSe<Ch>:]FREQuency:COMPression:POWer:POINts
5.2.7.3 Converter Compression setup dialog
Similar to the Amplifier Compression setup dialog, but with additional configuration
possibilities for frequency converting DUTs.
Access: Meas softtool > "Mixer Params" > "Gain Compression" > "Setup Frequency
Converting DUT"
5.2.8 Time Domain tab
The "Time Domain" tab is enabled by software option R&S ZNA-K2. It mirrors the Time
Domain tab of the Trace – [Trace Config] softtool.
5.2.9 Time Gate tab
The "Time Gate" tab is enabled by software option R&S ZNA-K2. It mirrors the Time
Gate tab of the Trace – [Trace Config] softtool.
