R&S ZNA67 User Manual

GUI reference
R&S
®
ZNA
775User Manual 1178.6462.02 ─ 20
If the selected number of "Diagrams" exceeds the number of traces, some of the new
diagrams are created with a default trace.
Tip: To vary the size and position of the diagrams, drag and drop the separating
frames or use the functions in the "Diagram" tab.
Remote command:
DISPlay:LAYout
Diagrams / Rows / Columns
Selects the number of "Diagrams" (or "Rows" and "Columns") to which the traces in the
active recall set are split. The split is performed according to the selected Split Type.
If the entered number of "Diagrams" exceeds the number of previously existing traces,
some of the new diagrams are created with default traces.
For a "Split Type" other than "Rows + Cols", only the total number of "Diagrams" can
be specified.
Remote command:
DISPlay:LAYout:GRID
Additional Functionality: SCPI Commands
The analyzer provides remote control commands for efficient diagram handling. The
commands listed below extend the functionality of the "Display > Diagram" and "Dis-
play > Split" softtool panels. For programming examples, refer to Chapter 8.2.2.6, "Cre-
ating diagrams", on page 1607.
Remote command:
DISPlay:LAYout:APPLy
DISPlay:LAYout:DEFine
DISPlay:LAYout:EXECute
DISPlay:LAYout:JOIN
5.18.3 Config tab
Displays or hides controls and information elements of the screen and controls the
appearance of the individual diagrams.
Hiding the controls and information elements leaves more space for the diagrams. All
elements can be shown or hidden simultaneously.
Related information
Refer to Chapter 4.2.1, "Display elements of a diagram", on page 97.
Display softtool

R&S ZNA67 Specifications

General

Frequency Range	10 MHz to 67 GHz
Number of Ports	4
Display	12.1" touchscreen
Impedance	50 Ω
Output Power Range	-30 dBm to +10 dBm
Connector Type	2.4 mm
IF Bandwidth	10 MHz
