Model 8210/8250 Maintenance Manual Section 7. Component Procedures
Electrical Components Wiring Harness
Publication: 1146945/001, Revised: 25 Sep 2018 7-71
• the phase cables at the traction motor
terminal block should be looped enough to
allow full turning from left to right without
contact with the lift linkage.
Figure 7-87.
