Model 8210/8250 Maintenance Manual Section 7. Component Procedures
Electrical Components Traction Motor
Publication: 1146945/001, Revised: 25 Sep 2018 7-87
Table 7-6. Traction Motor Component Legend
Item No. Description Item No. Description
1 Cap Screw, Socket Head 21 Cover, Speed Sensor
2 Cover, Motor 22 Cap Screw, Socket Head
3 Ring, Retaining 23 Washer, Lock
4 Spacer 24 Sensor, Speed
5 Bearing, Ball 25 Washer
6 Key, Fitted 26 Cable Tie
7 Armature 27 Sealing Strip
8 Seal, Shaft 28 ‘U’ Identification Label
9 Ring, Retaining 29 ‘W’ Identification Label
10 Bearing, Ball 30 ‘V’ Identification Label
11 Stator 31 Terminal Board
12 Insulating Sleeve 32 Cap Screw, Socket Head
13 Pin, Threaded 33 Washer, Lock
14 Nut, Pinion 34 Nut
15 Grommet 35 Plug Holder
16 Seal, Shaft 36 Screw
17 Pinion, Speed Sensor 37 Washer
18 Washer 38 Plug and Wedge Lock
19 Screw, Hex Head 39 Plug and Wedge Lock
20 Nut 40 Brake Hub Mounting Location
