Section 7. Component Procedures Model 8210/8250 Maintenance Manual
Hydraulic Fluid Hydraulic Components
7-96 Publication: 1146945/001, Revised: 25 Sep 2018
11. Reconnect the lift cylinder hose. Refer to
Table A-10 on page A-12 for correct torque
values.
12. Remove the vent plug and fill the reservoir
to within 1 in. (25.4 mm) below the filler
port elbow with the recommended
hydraulic fluid. See “Lubrication
Equivalency Chart” on page A-2.
13. Replace the vent plug.
14. Connect the battery connector. Place the
Main ON/OFF Switch in the ON position.
If equipped with the optional keypad, enter
your PIN-key code and then press the
green ON ( | ) key.
15. Raise and lower the forks several times to
purge air from the system.
16. Return the forks to the lowest position and
check the fluid level. Add fluid if
necessary.
17. Install the main harness bracket and the
tractor covers.
18. Dispose of the waste fluid correctly.
