– Preselect the direction before setting RUN command, otherwise direc-
tion will change (with a possible "dead zone time").
● When setting E0.00 "2-wire / 3-wire running control", 3-wire con-
trol can only be selected after the 3-wire input terminal has been
mapped. Otherwise, “PrSE” warning occurs.
● When setting E0.01 ~ E0.05, the 3-wire input terminal can only be
unselected after the 3-wire control has been disabled. Otherwise,
“PrSE” warning occurs.
E0.01 Terminal X1
Setting range 0 ~ 28
Minimum unit 1
Factory default 0
E0.02 Terminal X2
Setting range 0 ~ 28
Minimum unit 1
Factory default 0
E0.03 Terminal X3
Setting range 0 ~ 28
Minimum unit 1
Factory default 0
E0.04 Terminal X4
Setting range 0 ~ 28
Minimum unit 1
Factory default 0
E0.05 Terminal X5
Setting range 0 ~ 28
Minimum unit 1
Factory default 0
E0.06 ~ E0.09: Reserved
5 external digital input terminals are available with PNP and NPN input modes.
● 0: No action (The frequency converter has no action even if there is input sig-
nal. Multiple selection is possible.)
● 1: Multi-speed terminal 1
● 2: Multi-speed terminal 2
● 3: Multi-speed terminal 3
Bosch Rexroth AG
Parameter Settings
EFC 3600
90/259
DOK-RCON03-EFC-3600***-IT03-EN-P
