Communication parameter configuration
Communication related parameter settings
Parameter Name Setting range of parameter
b1.00 First frequency setting source 5: Set by communication
b1.02 First RUN command source 2: Set control commands by communication
b1.16 Second frequency setting source 5: Set by communication
b1.17 Second RUN command source 2: Set control commands by communication
H0.00 Communication protocols 1: PROFIBUS protocols
H0.03 Local address 1 ~ 126
H0.08
Communication disconnection detec-
tion time
0.0 ~ 60.0s (0.0s: deactivated)
H0.09 Communication disconnection action 0: Stop; 1: Continue running
H0.10 PZD3 setting 0 ~ 20
H0.11 PZD4 setting 0 ~ 20
H0.12 PZD5 setting 0 ~ 20
H0.13 PZD6 setting 0 ~ 20
H0.14 PZD7 setting 0 ~ 20
H0.15 PZD8 setting 0 ~ 20
H0.16 PZD9 setting 0 ~ 20
H0.17 PZD10 setting 0 ~ 20
Tab. 13-38: PROFIBUS-DP communication parameters
In the operation controlled by communication, if the frequency con-
verter is stopped by the Stop key on the operating panel, the fre-
quency converter stops responding to the control commands by
communication. To enable the control by communication, re-power
the frequency converter or send Stop command to the frequency
converter by communication.
EFC 3600 Bosch Rexroth AG
Communication Protocols
DOK-RCON03-EFC-3600***-IT03-EN-P
209/259
