– 11: set by parameter ‘Acceleration time 4’ E2.04
– bit1 and bit0
– 00: set by parameter ‘Deceleration time 1’ b1.10
– 01: set by parameter ‘Deceleration time 2’ E2.01
– 10: set by parameter ‘Deceleration time 3’ E2.03
– 11: set by parameter ‘Deceleration time 4’ E2.05
● Example: Forward rotation, setting acceleration time with ‘Acceleration
time 2’ E2.00, setting deceleration time with parameter ‘Deceleration
time 3’ E2.03
– Forward: bit4 = 0
– setting acceleration time with ‘Acceleration time 2’ E2.00: bit3 = 0,
bit2 = 1 ('bit3 and bit2' = 01)
– setting deceleration time with ‘Deceleration time 3’ E2.03: bit1 = 1,
bit0 = 0 ('bit1 and bit0' = 10)
The binary format of the example is shown as the table below.
0 0 1 1 0
Tab. 7-17: Example binary format
Conversion of binary format to decimal format:
[E2.23] = 0 × 2
4
+ 0 ×2
3
+ 1 × 2
2
+ 1 × 2
1
+ 0 × 2
0
= 6
E2.24
Stage 1 running time Factory default 0.0
Setting range 0.0...5,000.0 s Minimum unit 0.1
Used to set the running time of stage 1, related parameter ‘Logic control time
factor’ E2.22.
E2.25
Stage 2 action selection Factory default 0
Setting range 0...31 Minimum unit 1
E2.26
Stage 2 running time Factory default 0.0
Setting range 0.0...5,000.0 s Minimum unit 0.1
E2.27
Stage 3 action selection Factory default 0
Setting range 0...31 Minimum unit 1
E2.28
Stage 3 running time Factory default 0.0
Setting range 0.0...5,000.0 s Minimum unit 0.1
E2.29
Stage 4 action selection Factory default 0
Setting range 0...31 Minimum unit 1
E2.30
Stage 4 running time Factory default 0.0
Setting range 0.0...5,000.0 s Minimum unit 0.1
E2.31
Stage 5 action selection Factory default 0
Setting range 0...31 Minimum unit 1
E2.32
Stage 5 running time Factory default 0.0
Setting range 0.0...5,000.0 s Minimum unit 0.1
