Model FELB Typecode
FELB
Quantity
FELR Typecode FELR Type
FELR
Quantity
0K40 Internal – 0150-N750R-D 750Ω/150W 1
0K75 Internal – 0150-N700R-D 700Ω/150W 1
1K50 Internal – 0520-N350R-D 350Ω/520W 1
2K20 Internal – 0520-N230R-D 230Ω/520W 1
4K00 Internal – 0780-N140R-D 140Ω/780W 1
5K50 Internal – 1K04-N090R-D 90Ω/1040W 1
7K50 Internal – 1K56-N070R-D 70Ω/1560W 1
11K0 Internal – 02K0-N047R-D 47Ω/2.0kW 1
15K0 Internal – 01K5-N068R-D 68Ω/1.5kW 2
18K5 FELB02.1N-30K0 1 10K0-N028R-A 28Ω/10.0kW 1
22K0 FELB02.1N-30K0 1 10K0-N022R-A 22Ω/10.0kW 1
30K0 FELB02.1N-45K0 1 12K5-N017R-A 17Ω/12.5kW 1
37K0 FELB02.1N-45K0 1 10K0-N032R-A 32Ω/10.0kW 2
45K0 FELB02.1N-30K0 2 10K0-N024R-A 24Ω/10.0kW 2
55K0 FELB02.1N-45K0 2 12K5-N018R-A 18Ω/12.5kW 2
75K0 FELB02.1N-45K0 3 12K5-N020R-A 20Ω/12.5kW 3
90K0 FELB02.1N-45K0 3 12K5-N020R-A 20Ω/12.5kW 3
Tab. 10-10: Brake resistor selection_OT = 20 %
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 203/259
Rexroth Frequency Converter Fv
Accessories
