AREA C
Removal
1. Set the machine to A4 / 8.5x11”.
2. Remove Front and Rear cover (
3.3.1 ).
3. Remove Infeed cover (
3.3.2 ).
4. Disconnect connector [A] to motor M7 (
x1 ).
5. Disconnect connector [B] to sensor Q15 (
x1 ).
6. Loosen allen screw [C] and remove the stop ring (
x1 ).
7. Remove screws [D] on front side of the Booklet maker (
x2 ).
8. Remove the same screws on the rear side of the Booklet maker (
x2 ).
9. Remove the Fold knife motor M7 module.
10. Remove sensor Q15 [E].
11. Remove Crank journal [F] with an 17 mm open wrench.
12. Remove screw and washer [G] (
x1, x1 ).
13. Remove the Crank wheel [H].
14. Remove screws [ I ] to the motor (
x3 ).
Replacement
1. Reinstall screws [ I ] to the motor (
x3 ).
NOTE: DO NOT TIGHTEN THE SCREWS.
2. Reinstall the Crank wheel [H].
3. Reinstall screw and washer [G] (
x1, x1 ).
4. Tighten screws [ I ] to the motor (
x3 ).
5. Reinstall Crank journal [F] with an 17 mm open wrench.
NOTE: Make sure to install the smaller end [J] of the Crank journal.
6. Reverse the rest of the removal procedure.
