21 August 2006
3-80
BOOKLET QUALITY ADJUSTMENT
Purpose
The purpose is to ensure that the staples are parallel to the edge of the sets.
Removal
1. Set the machine to A3 / 11x17”.
2. Open Top cover.
3. Remove the rear stapler head (
3.4.12 ).
4. Fold an A4 / 8.5x11” paper lengthwise by hand, and feed the paper down be
-
tween the side guides (LEF).
5. Feed the paper so that the straight edge [A] is positioned against the Staple
stop gate.
6. Enter the Service program (
5.1.1 ).
7. Start the Staple / Fold positioning motor M9.
8. Step the motor to align the straight edge [A] with the locating holes [B] in the
paper path.
9. The straight edge [A]
must align with the locating holes on both sides.
Adjustment
1. Loosen screw [C] (
x1 ).
2. Insert a screwdriver in the notches [D], rotate to align the locating holes [B]
with the straight edge [A] ( x1 ).
3. Tighten the screw [C] (
x1 ).
4. Check according to step 9 in Removal section.
Replacement
1. Reverse the removal procedure.
