Ricoh bk5010 - EEPROM Values

5-10
21 August 2006 SERVICE PROGRAM MODE
EEPROM Values
Index Default Function
0 Password 107 The password to enter service mode can
be changed here.
1 STD Trim 004.50 Standard trim margin that is default pre-
sented in the user menu. Value reects how
many millimetres that will be trimmed off from
the longest sheet (centre fold) in the booklet.
2 Side Jog Offset ≈321 mm Reference regarding position for paper
size adjustment. Value reects paper size
width at home position.
3 Rear Offset ≈270 mm Reference regarding position for paper
size adjustment. Value reects paper size
length at home position.
4 Staple 0 - The counter for the stapler. Value reects
the count of how much the stapler heads
have cycled.
5 Fold 0 - The counter for the folder. Value reects the
count of how much the fold knife has cycled.
6 Trim knife 0 - The counter for the trimmer. Value reects
the count of how much the trimmer knife
has cycled.
7 Cover feed 0 - The counter for the cover feeder. Value
reects the count of how many sheets the
cover feeder has delivered.
8 Book Folder 0 - The counter for the Book Folder. Value
reects the count of how many Books the
Book Folder has delivered.
9 BK-M1 Speed
Low
≈01000 The values reect calibration of Infeed motor
BK-M1, Pre Infeed motor BK-M19 and Fold
roller motor BK-M6 at power on.
10 M1 Speed High ≈01400
11 BK-M19 Speed
Low
≈01900
12 BK-M19 Speed
High
≈02700
13 BK-M6 Speed ≈01900
14 CF-M15 Speed
Low
≈01300 The values reect calibration of Feed motor
CF-M15 at service.
15 CF-M15 Speed
High
≈01900
