1-27
Installation
04 October 2007
1. Remove the nut [A] ( x 1).
NOTE: Nut will be used later when installing the Cover Feeder.
2. Remove the screws [B] (
x 2).
NOTE: Screws will be used later when installing the Cover Feeder.
[A] [B]
Removal of cover Feeder dummy
COVER FEEDER INSTALLATION
To Next Page
