1-45
Installation
04 October 2007
4. Looking from behind the system, make sure that the Trimmer is parallel with
the Booklet Maker [E] ± 2mm. If necessary, adjust by turning the two nuts [F]
on the outfeed side of the Trimmer.
[E]
[F]
TRIMMER INSTALLATION
