1-69
Installation
04 October 2007
17. If a Cover Feeder CF5010 is installed:
A. Prepare a 15mm/ high stack of A4/8.5 x 11” covers.
B. Make sure that the ink has dried out well, to avoid smearing.
C. Make sure that the covers are well fanned to avoid misfeeds or double-feeds.
D. Align the covers well to achieve a reliable collating operation and good
nishing result.
E. Press down the green marks on Paper bin and load the covers.
F. Move the adjustable side guides up against the covers, until there is no clearance.
G. Set up the Cover Feeder to Cover ON, the fan will start and the Cover
Feeder will prefeed the rst cover to be ready for the set from the copier.
18. Set up the Booklet Maker to Auto paper size.
19. Send ve 2 sheet booklets of A4/8.5 x 11” (8 pages of A5/8.5 x 5.5 = a booklet
containing 2 sheets of A4/8.5 x 11”) to the Booklet maker system.
20. Check for the correct feeding of the set from the nisher.
NOTE: The paper should enter in the middle of the infeeder. If not, adjust the
Booklet maker according to section ( 1.3.3 ).
21. If a Cover Feeder CF5010 is installed - check that the covers are correctly fed
into the Booklet maker.
22. Check if the sets have been trimmed correctly.
23. Check that the booklet
not has a Book folded spine.
24. If a Cover Feeder CF5010 is installed:
A. Set up the Cover Feeder to Cover OFF and remove all covers from the bin.
Use the Purge mode to completely empty the Cover Feeder from covers.
B. Prepare a 15mm high stack of A3/11 x 17” covers.
C. Repeat step 17 B to 18 G.
25. Send ve 10 sheet booklets of A3 / 11x17” (40 pages of A4/8.5 x 11 = a book
-
let containing 10 sheets of A3 / 11x17”) to the Booklet maker system.
26. Check for the correct feeding of the set from the nisher.
NOTE: The paper should enter in the middle of the infeeder. If not, adjust the
Booklet maker according to section ( 1.3.3 ).
27. If a Cover Feeder CF5010 is installed - check that the covers are correctly fed
into the Booklet maker.
28. Check if the sets have been trimmed correctly.
29. Check that the booklet has a square formed spine.
BOOK FOLDER INSTALLATION
