Ricoh TH-C1b - Power Requirements; Space Requirements

INSTALLATION REQUIREMENTS 10 February 2005
1-2
1.1.3 POWER REQUIREMENTS
!CAUTION
1. Insert the plug firmly in the outlet.
2. Avoid using an outlet extension plug or cord.
3. Ground the machine.
1. Input voltage level: 120 V, 60 Hz, More than 12 A
220 ∼ 240 V, 50/60 Hz, More than 8 A
110 V, 50/60 Hz, More than 13A
2. Permissible voltage fluctuation: ±10%
3. Do not put or place anything on the power cord.
1.1.4 SPACE REQUIREMENTS
B156I501.WMF
A
: Over 100 mm (4")
B: Over 100 mm (4")
C: Over 550 mm (22")
D: Over 750 mm (29.6")
A C
B
D
